1955.7.9.1

Adjustable screw stock in three pieces [.1-.3] [SM (Verve) 28/07/2014].

1955.7.9.1

Digital asset copyright: Pitt Rivers Museum, University of Oxford

Terms and Conditions

If you wish to order a high-resolution image and/or licence its use for print or web publication, exhibition, film, promotional product or any other use, whether in the academic or commercial sector of any print run, then please visit photographic services.

Collection type
Object
Description
Adjustable screw stock in three pieces [.1-.3] [SM (Verve) 28/07/2014].
Long description
Adjustable screw stock in three pieces [.1-.3] [.1] is tool comprising a frame with two thin arms and a rectangular hole in the centre which has two vice-like pieces of iron with a bolt 'thread' cut into the centre of them. [.2] is an iron key, which pushes the vice closed. [.3] is an iron rod, partially cut with a bolt thread. [SM (Verve) 28/07/2014] [SM (Verve) 28/07/2014].
Geographical reference
India
Asia > Southern Asia > India
Kerala
Person
Maker Chinnian Asari
Field collector Derek G. Jenkins
Field collector Mary G. Jenkins
PRM source Derek G. Jenkins
PRM source Mary G. Jenkins
Date / Period
Date made: Before 1955
Date collected
By 1955
Acquisition information
Donated: 1955
Materials and processes
Material Iron Metal, Process Forged (Metal), Process Perforated, Process Grooved
Dimensions
Length: max 246 mm, Width: max 46 mm
Object numbers
Accession number: 1955.7.9.1 Accession number: 1955.7.9.2 Accession number: 1955.7.9.3
Research and responses

According to the OED Online, screw stock is another name for a die. [CW 10/8/2000]

This tool was used for cutting the 'thread' into bolts [SM (Verve) 28/07/2014]
